Name: EPSON TM-U220D POS PRINTER
SKU: 4690
Availability: OutOfStock

Component	Specification
Product Name & Model	Epson TM-U220D
Printing Method	9-pin serial impact dot matrix
Printing Speed	– 4.7 lines/sec (40 columns, 16 cpi)- 6.0 lines/sec (30 columns, 16 cpi)
Dot Density	180 x 180 dpi
Print Font	– Font A: 9 x 9- Font B: 7 x 9 (default)
Characters Per Inch	– Font A: 14.5 cpi / 13.3 cpi- Font B: 17.8 cpi / 16 cpi
Character Size (W x H)	1.2 x 3.1 mm or 1.6 x 3.1 mm
Character Set	95 Alphanumeric, 48 International, Extended graphics: 128 x 12 pages
Paper Width and Diameter	– 76.0 ± 0.5 mm × dia. 83.0 mm- 69.5 ± 0.5 mm × dia. 83.0 mm- 57.5 ± 0.5 mm × dia. 83.0 mm
Receive Data Buffer	4 KB or 40 bytes
Interface	RS-232C, Bidirectional Parallel; Optional: USB, 10 Base-T Ethernet
Two-Colour Printing	Yes
Auto Cutter	No
Wall Hanging Install	Yes
Dimensions (D x W x H)	160 x 248 x 138.5 mm
Mass	Approx. 2.3 kg
Power Supply	AC adapter (DC +24 V ± 7%)
Power Consumption	– Operating: Approx. 38 W- Standby: Approx. 2.2 W
Reliability	– MTBF: 180,000 hours- MCBF: 18 million lines- Printer Mechanism Life: 7.5 million lines
Standard Accessories	– Dedicated ribbon cassette (ERC-38 B/R)- Roll paper- User manual- AC adapter

Key Features:
