The Rongta RP80VI is a direct thermal barcode label printer with high-speed printing up to 150 mm/s. It features automatic label positioning, stripping, and detection, supporting multiple barcode formats. Suitable for logistics, retail, and warehouse labelling.
Description
Component
Specification
Model
Rongta RP80VI
Printing Method
Direct Thermal Printing
Resolution
203 dpi
Paper Width
24 – 82 mm
Printing Speed
150 mm/s, 127 mm/s
Interfaces
Serial, Parallel, USB, Ethernet
Memory
DRAM: 8 MB, FLASH: 4 MB
Heating Head Temperature Detection
Thermistor
Paper End Detection
Photoelectric Sensor
Paper Exist Detection
Photoelectric Sensor
Printing Head Position Detection
Micro Switch
Supported Barcodes
UPC-A, UPC-E, EAN8, EAN13, CODE39, ITF, CODABAR, CODE93, CODE128, PDF417, QR Code
Character Enlargement/Rotation
1-8x horizontal & vertical; rotate at 90°, 270°
Graphics Support
BMP, ICO, EMF, WMF (download to FLASH, DRAM)
Media Types
Thermal roll paper, stickers, thermal label paper
Paper Roll Diameter
Max: 85 mm, Min: 25 mm
Paper Out Method
Tear or Strip
Power Supply
Input: 24V DC, 2.0A
Weight
Approx. 1.5 kg
Dimensions (LxWxH)
237 x 146 x 130 mm
Working Temperature/Humidity
5 – 45°C, 20 – 80% RH (non-condensing)
Storage Temperature/Humidity
-40 – 55°C, ≤90% RH (non-condensing)
Machinery Lifespan
100 km
