The XP-365B is a direct thermal barcode and label printer with up to 127 mm/s printing speed. It supports various barcode formats, paper types, and connectivity options including USB, serial, parallel, and LAN. Suitable for retail, warehousing, and logistics applications.
Description
Component
Specification
Model
XP-365B
Printing Method
Direct Thermal
Resolution
203 DPI
Paper Width
20 – 58 mm
Printing Speed
Max: 127 mm/s, Min: 101 mm/s
Memory
DRAM: 2 MB, FLASH: 2 MB
Printer Head Temperature Test
Touch switch
Paper Detection
Photosensor
Interfaces
Serial, Parallel, USB, LAN, Serial+USB
Supported Barcodes
CODE128, EAN128, ITF, CODE39, CODE93, EAN13, EAN13+2, EAN13+5, EAN8, EAN8+2, EAN8+5, CODABAR, POSTNET, UPC-A, UPCA+2, UPCA+5, UPC-E, UPCE+2, UPC-E+5, CPOST, MSI, MSIC, PLESSEY, ITF14, EAN14
Barcode Settings
Single character: FONT 0 to FONT 8
Character Extension/Rotation
Extend 1-10x horizontally and vertically, rotate 0°, 90°, 270°, 360°
Graphics
Supports PCX and BMP image download to FLASH and DRAM
Supported Media Types
Thermal paper and self-adhesive label paper
Print Width
16 – 82 mm
External Roll Diameter
Max: 120 mm
Inner Roll Diameter
Min: 25 mm
Paper Type
Tear-off and peel-off
